This SAE Recommended Practice establishes the location of drivers’ eyes inside a vehicle. Elliptical (eyellipse) models in three dimensions are used to represent tangent cutoff percentiles of driver eye locations. This document applies to Class A Vehicles (Passenger Cars. SAE J JUN SAE Recommended Practice. 3.' Report of the Body Engineering Committee, approved November , completely revised, Truck and Bus. This paper describes the development of the fixed seat eyellipse in the October revision of SAE. Recommended Practice J The eye locations of
